2D Construction Drawings

Construction drawings from ibmv are fully detailed and production ready, including:

  • All necessary shape forms

  • Very clear and specific welding instructions

  • Full structural reinforcements

  • Complete material data specification, grades of steel, thicknesses, the mass of each component, etc.

  • Special production details, i.e. surface treatments, coatings, etc.
